- ★【𝐑𝐄𝐅𝐄𝐑𝐄𝐍𝐂𝐄】– This torque chart provides comprehensive information on tightening torque specifications for both SAE and metric bolts. It covers various bolt sizes and types, including hex bolts, flange bolts, and carriage bolts, ensuring that users have access to accurate and reliable torque values for a wide range of applications. Tightening torque wrench chart for SAE bolts: UNC and UNF 1/4 <> 1-1/2 * Not Lubricated and Lubricated * Grade 1, Grade 2, Grade 5/5.2, and Grade 8.
- ★【𝐌𝐀𝐆𝐍𝐄𝐓 𝐏𝐎𝐒𝐓𝐄𝐑 𝐃𝐄𝐒𝐈𝐆𝐍】– The torque chart is designed as a magnet poster, allowing it to be easily attached to any metal surface. This convenient feature ensures that the chart is always within reach, providing quick access to vital information whenever needed. It eliminates the need for wall space or complex mounting options, making it suitable for use in workshops, garages, or even on machinery.
- ★【𝐖𝐑𝐄𝐍𝐂𝐇 𝐈𝐍𝐓𝐄𝐑𝐂𝐇𝐀𝐍𝐆𝐄𝐀𝐁𝐈𝐋𝐈𝐓𝐘】– The chart includes a wrench interchangeability section, which helps users select the appropriate wrench size for a specific bolt. This saves time and eliminates the need for trial and error, ensuring that the right tool kit is chosen for the job. By providing this information, the chart promotes efficiency and accuracy in bolt tightening operations.
- ★【𝐀𝐃𝐃𝐈𝐓𝐈𝐎𝐍𝐀𝐋 𝐈𝐍𝐅𝐎𝐑𝐌𝐀𝐓𝐈𝐎𝐍】– In addition to torque values, the torque chart provides other essential information to enhance its usefulness for machinist. It includes details on recommended lubricants for bolt installation, prevailing torque values, and important notes related to proper bolt assembly. This comprehensive information assists users in making informed decisions and ensures that all relevant factors are considered during the tightening process.
- ★【𝐖𝐀𝐓𝐄𝐑𝐏𝐑𝐎𝐎𝐅 & 𝐃𝐔𝐑𝐀𝐁𝐋𝐄 𝐂𝐎𝐍𝐒𝐓𝐑𝐔𝐂𝐓𝐈𝐎𝐍】– The torque chart is constructed using durable and high-quality materials. It is designed to withstand the demands of workshop environments, making it suitable for use in various industries. This chart sheet is waterproof, ensuring that the information remains readable and intact even in humid or wet conditions. This feature is particularly beneficial for applications in automotive, marine, or outdoor equipment industries.
- ★【𝐂𝐎𝐌𝐏𝐀𝐂𝐓 & 𝐏𝐎𝐑𝐓𝐀𝐁𝐋𝐄】– With its compact size of 11.8" x 8.3", the torque screwdriver chart is convenient to carry, store, and transport. It can be easily placed in toolboxes, backpacks, or pockets, allowing users to have torque information readily available wherever they go. Its portability makes it an ideal tool for professionals working in the field or for enthusiasts who frequently engage in DIY projects.
- ★【𝐏𝐑𝐎𝐌𝐎𝐓𝐄𝐒 𝐒𝐀𝐅𝐄𝐓𝐘 & 𝐄𝐅𝐅𝐈𝐂𝐈𝐄𝐍𝐂𝐘】– By providing accurate torque values, the digital torque wrench chart ensures that bolts are tightened to the recommended specifications. This promotes safety by preventing loose or overtightened bolts, which can lead to failures or accidents. Moreover, accurate bolt tightening improves the overall efficiency and reliability of mechanical connections, reducing the risk of costly repairs or rework.
The Useful Magnets Comprehensive Reference Tightening Torque Chart for SAE & Metric Bolts is a valuable tool designed to simplify the process of tightening bolts. This convenient magnet guide, available as a waterproof SAE chart measuring 11.8" x 8.3", is an essential addition to any workshop, garage, or toolbox. By providing comprehensive information on torque specifications, it ensures precise and accurate bolt tightening, promoting safety and efficiency in various applications.
When it comes to securing bolts, the appropriate tightening torque wrench set is crucial. Insufficient torque can lead to loose bolts, while excessive torque can cause damage to the bolt, the mating surfaces, or the thread. The Comprehensive Reference Tightening Torque Chart from Useful Magnets acts as a reliable reference, eliminating guesswork and promoting proper torque application.
This chart is designed for both SAE (Society of Automotive Engineers) and metric bolt assortment sizes, making it versatile and suitable for a wide range of applications. It covers various bolt types, including hex bolts, flange bolts, carriage bolts, and more. By providing the recommended torque values for each bolt size and type, the chart ensures consistent and accurate tightening, improving the overall quality and reliability of mechanical connections.
𝐒𝐏𝐄𝐂𝐈𝐅𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒
- Size - 11.8" X 8.3"
- Brand - Useful Magnets
- Dimensions - 11.8 x 8.3 x 0.04 inches
- Shape – Square
- Country of Origin - Canada
𝐈𝐧𝐜𝐥𝐮𝐝𝐞𝐬:
1. Tightening torque for SAE bolts: UNC and UNF 1/4 <> 1-1/2 Not Lubricated and Lubricated Grade 1, Grade 2, Grade 5/5.2, Grade 8 2. Tightening torque for METRIC bolts: Standard and Fine Pitch M6 <> M36 Not Lubricated and Lubricated Class 4.6, Class 8.8, Class 10.9, Class 12.9 3. WRENCH / SPANNER INTERCHANGE CHART SAE <> METRIC, 10 most common sizes 4. Bolt
